  1. landlordray

    landlordray New Member

    Hello,

    I have a rental property and had a new combi boiler fitted 2 years ago.
    No problems at all with the boiler, my only niggle is that the external condensate pipe is 32mm and fully covered with black insulation.

    This pipe runs almost 3 metres across the outside wall of the kitchen and then a further 2 metres round a corner to the drain.
    As the property was tenanted at the time I ( and the tenant ) had just accepted this.

    This is really unsightly and now that the tenants have left and I am looking to re-let the property, I would like to have this changed, as I feel this is putting people off when they come to view the property as this hits you in the eye as soon as you approach the front door.

    Could the 32mm ( black insulated ) pipe be replaced by a 40mm ( or larger ) none insulated white PVC pipe which would look more cosmetically acceptable?

    thanks

  2. Ric2013

    Ric2013 Plumber Top Contributor!!

    Could the pipe not be run mostly internally instead?

  3. SimonG

    SimonG Trusted Plumber Top Contributor!!

    32mm is minimum. What part of the country are you?

  4. landlordray

    landlordray New Member

    Hi, no the pipe runs from the boiler vertically about 2 feet, then outside.
    There is no facility to run the pipe internally due to kitchen cupboards etc.

    • Like Like x 1
  5. Ric2013

    Ric2013 Plumber Top Contributor!!

    The OP is suggesting a LARGER one not a smaller one, Simon. But he wants to run it uninsulated.

  6. SimonG

    SimonG Trusted Plumber Top Contributor!!

    Just saying 32mm is minimum so the world is his mollusc when it comes to something bigger.

    I always run mine in 40mm uninsulated.

  7. landlordray

    landlordray New Member

    Yes that's it exactly

  8. landlordray

    landlordray New Member

    so 40 mm un-insulated would be OK ?

  9. Ric2013

    Ric2013 Plumber Top Contributor!!

    What is actually considered good practice then? 32mm uninsulated is okay?
    OP - in what part of the country is this house and is it urban, rural (exposed or coastal), or suburban?

  10. SimonG

    SimonG Trusted Plumber Top Contributor!!

    MI's state 32. I use 40. Always have more 40 bits than 32. For your standard winter 40 uninsulated would be no problem.

    2010 110mm was freezing solid. Dripping tap left without repair.

  11. landlordray

    landlordray New Member

    Hi, property is a 3 bed terraced house in the north east of england. It is on a large suburban estate.
    It is not coastal or particularly exposed

    • Like Like x 1
  12. Ric2013

    Ric2013 Plumber Top Contributor!!

    I think the answer is yes go ahead?

  13. landlordray

    landlordray New Member

    Thanks for all the speedy replies.
    The boiler service is due shortly so I will get the guys to replace the condensate pipe with 40mm when they come to do the service.

    cheers

  14. Craig Watson

    Craig Watson Plumber GSR Top Contributor!!

    Run it under kitchen units in the the plinth space then terminate to outside as close to the drain as possible. With your average winter it's unlikely to freeze in a 32mm pipe anyway but the less pipe exposed the less chance of it happening when we do get a bad winter. Could save you 1 or 2 callouts

  15. landlordray

    landlordray New Member

    Thanks, I appreciate the reply but it would be a big job to re-route internally.
    one of the internal kitchen walls has a radiator fitted so pipe would need to go underneath and would need to be boxed in as it would be unsightly if left on show, in any event there is no room to do this anyway.
    This is just one of the obstacles I would need to overcome to have anything done internally.

    Much easier to do externally
